ZQK-20 notch sample preparation machine/notching machine/notch cutter for Charpy impact sample is used to process the non-metal material impact test specimen notch, such as the plastics, organic glass etc., it’s an ideal notching machine for plastic impact test. Conform with standard ISO179, ISO180 etc.
Manual adjust sample position, motor cutting.
Notch blade (A: 45°±1° R0.25 B: 45°±1° R1 C: 45°±1° 0.1 )
the notch types from ISO 179
| Model | ZQK-20 |
| Blade length | 50mm |
| Cutting speed | 60rpm |
| Motor power | 60W, 220V |
| Cutting stroke | 26mm |
| Dimensions | 420*280*380mm |
| Weight | 30Kg |
| Standard Accessories | Frame, Notch blade (A: 45°±1° R0.25 B: 45°±1° R1 C: 45°±1° 0.1 ), spanner, power cord, manual etc. |
Frame,
Notch blade (A: 45°±1° R0.25 B: 45°±1° R1 C: 45°±1° 0.1 ),
spanner,
power cord,
manual etc.
ISO 179: “Plastics -- Determination of Charpy impact properties”
ASTM D6110: “Standard Test Method for Determining the Charpy Impact Resistance of Notched Specimens of Plastics”
ISO 180: “Plastics -- Determination of Izod impact strength”
ASTM D256: “Standard Test Methods for Determining the Izod Pendulum Impact Resistance of Plastics”
